Technicial Specifications
MEASURES AND WEIGHTS
Unladen weightkg 3150 – 3900
Tongue load emptykg250 – 600
Max. permissible vertical loadkg2000
Axle load emptykg2900 – 3300
Max. permissible axle loadkg8000
Overall length max.(transport position)cm760
Transport width (transport position)cm255
Transport heightcm380 – 400
Track widths mechanically adjustablecm150 – 225
Ground clearance axlecm70


TANK
Mixture tank nominal capacityliter3800
Mixture tank actual capacityliter4000
Fresh water tankliter400
Hand wash tankliter15


SPRAYING BOOM
Working widthsm18 – 30
Sections (depending on the boom) 5 – 18
Working height m0.50 – 1.95*
Pump capacity Basiclitres/min270
Max. discharge at the boom for basiclitres/min200**
Working pressure, max.bar8
Working speedkm/h4 – 16
* Working height depends on the height of the coupling points at the tractor and the tyres
** The indicated application rates apply to water with a spraying pressure of approx. 5 bar. With other pressures the application rates may differ upward and downward.
< >
