DELTA A

GENERAL FEATURES

PICTURE GALLERY

VIDEO GALLERY

DESIGN DETAILS

TECHNICIAL SPECIFICATIONS

PRODUCT CATALOG

• The chassis models are produced with high quality material by robotic welding.

• The lock system with pressure spring support the  booms opening and closing stably .there is control panel that provides homogeneous and precise spraying.

• Cleanable filter system,3 membrane spraying pump with best performance,

• Fresh water tank independent from main tank.

• Long lasting and cleanable nozzle, the tank washing system, which enables the tank to be washed after spraying.

Model DELTA A4DELTA A6DELTA A8DELTA A10
Material of Tank PolyethylenePolyethylenePolyethylenePolyethylene
Capacity of Tank Lt4006008001000
Pump Model C71C71C71C71
Pump Flowl/min71717171
Pump PressureBar50505050
Control Panel OG 403OG 403OG 403OG 403
Work Widthm10101010
Nozzle TypeConical brass nozzle
Number of Nozzles 20202020
Distance Between Nozzlescm50505050
Boom Height Adjustment ManualManualManualManual
Boom's Folding Adjustment ManualManualManualManual
Required Tractor PowerHP40404040
Operating Speedr/min540540540540
Weightkg145156202210
Lengthcm135135148148
Widthcm75757575
Height cm135150156176
< >
